Durable XY-2B Hydraulic Mining Drilling Equipment For Solid Rock

Name: Durable XY2B Hydraulic Mining Drilling Equipment For Solid Rock
Brand: ShiTan
Price: 1 USD

China Durable XY-2B Hydraulic Mining Drilling Equipment For Solid Rock wholesale

Model Number : XY-2B

Type : water borehole drilling equipment

Power Type : Diesel

Usage : core drill

Voltage : 380V

Dimension(L*W*H) : 2500*1100*1700mm

Weight : 1450KG

Lifting capacity(KN) : 68

Vertical capacity(KN) : 46

Rated power KW : 22

Motor : Y180L-4

Brand Name : ShiTan

Certification : ISO9001

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Delivery Time : Within 7-12 days

Payment Terms : L/C, D/A, T/T, Western Union

Contact Now

Durable XY-2B Hydraulic Mining Drilling Equipment For Solid Rock

Product Specifications

Model Number	XY-2B
Type	Water borehole drilling equipment
Power Type	Diesel
Usage	Core drill
Voltage	380V
Dimension (L×W×H)	2500×1100×1700mm
Weight	1450KG
Lifting capacity (KN)	68
Vertical capacity (KN)	46
Rated power KW	22
Motor	Y180L-4

Durable Water Borehole Drilling Machine / XY-2B Hydraulic Core Drilling Rig

Main Features

Powerful performance in various land conditions including soil, sand, and hard rock
Three drill bit options (three-wing bit, alloy bit, diamond bit) suitable for both soft and hard ground, with diamond bit particularly effective for hard rocks
Hydraulic control system enhances working efficiency and reduces labor requirements
Mounted wheel or trailer design allows easy transportation by car or tractor
Flexible power options: diesel engine or electric motor available

Technical Parameters

Drilling depth	600m
Max open hole caliber	300mm
End hole caliber	75mm
Drilling angle	90°~65°
Dimension	2220 × 900 × 1800mm
Drill weight (without power)	1950kg

Spindle Specifications

Spindle speed	Forward 57 99 157 218 270 470 742 1024r/min Reverse 51 242r/min
Spindle stroke	450mm
Spindle inner diameter	96mm
Lifting capacity	6000kg

Hoist Specifications

Max single line lifting capacity	3000kg
Max single line lifting speed	0.52, 0.90, 1.42, 1.95m/s
Wire rope caliber	12.5mm
Wire rope length	50m
Reel diameter	200mm
Hug folldgate belt width	90mm

Oil Pump Specifications

Type	F532 gears oil pump
Flow	32 L/min
Pressure	20 Mpa

Power Options

Diesel engine	K4100D30
Electric motor	Y180L-4 22KW

Selection Guide

Project Type: Water well, borehole, exploration coring, foundation piling, blast holes, or geothermal heat project?
Drilling Depth: Required maximum depth (100m, 150m, 200m, 300m, etc.)
Borehole Diameter: Minimum and maximum required diameters (e.g., Max 200mm, Min 75mm)
Geological Conditions: Soft ground (soil, mud, sand), hard ground (rocks), or mixed conditions?

Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：

Pneumatic Drilling Rig / Air Drilling Rig（ST-180,ST-200,ST-260,ST-300,ST-350,ST-400,ST450,ST-450,ST-500, ST-600,ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B,GK180, GK200, GY150, GY200 and 30 impact drill rig,ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter

Good quality, professional after-sales service, welcome to order
